Argox AME-3230 B/W
• Easy to monitor power on when connecting with mobile computer or PDA.
• USB and RS-232 interfaces as well as Bluetooth connectivity (AME-3230B).
• Buzzer for media-out or cover-not-closed.
• Battery operation for eight hours on a single charge.
• Low battery does not affect print quality.
• Quick open/lock of battery cover without tools.
• IP54 certified with the environmental case.
The AME-3230 is a lightweight, palm-sized mobile printer that allows you to print labels or receipts anywhere you go. For mobile printing applications such as parking tickets, delivery or updating price tags on perishable retail items, the AME-3230 produces quick and simple labels and receipts from 1-inch to 3-inches wide on demand. Carry it on your belt and transmit data to the printer wirelessly using a Bluetooth equipped portable data terminal.
High performance features include a 32-bit CPU for up to 3ips printing speed, 203dpi print resolution for text and graphics, and 8M DRAM and 4M Flash ROM memory. The AME-3230 operates for eight hours on one battery charge, and provides smart power management and automatic low battery notification.
AME-3230 series possesses USB and RS-232 standard equipments, and provides Bluetooth (AME-3230B) and WiFi (AME-3230W) as optional accessories for users to create the most convenient environment. Barcode printing support includes 1D/GS1 Data bar, 2D/Composite codes and QR barcodes. The AME-3230 portable printer provides an exceptionally versatile solution for today’s growing mobile data management requirements.
|Printing Method||Direct Thermal|
|Printing Resolution||203 dpi(8 dots/mm)|
|Printing Speed||Max. 3 ips|
|Printing Length||Max. 40”(1016mm)|
|Printing Width||Max. 2.8”(72mm)|
|Memory||8MB DRAM, 4MB Flash ROM|
|CPU Type||32 bit RISC microprocessor|
|Sensors||Transmissive sensor x 1 (fixed, Left side)|
|Operation Interface||LED Indicator x 4, Button(Feed) x 2|
|Communication Interface||USB device, RS-232, Bluetooth 2.0(AME-3230B), WLAN(AME-3230W)|
|Fonts||Internal character sets standard. Ability to print any Windows True Type font easily|
|Wireless Security||AME-3230W: WEP-128, WPA-PSK (TKIP), WPA2-PSK (AES)|
|1D Barcodes||PPLZ: Code39, UPC-A, UPC-E, Postnet, Code128 subset A/B/C, Interleave 2 of 5, Interleaved 2 of 5 with check sum, Interleaved 2 of 5 with human readable check digit, Code 93, Code 39 with check sum digit MSI, EAN-8, Codabar, Code 11, EAN-13, Plessey GS1 Data bar (RSS), Industrial 2 of 5, Standard 2 of 5, Logmars|
|2D Barcodes||PPLZ: Maxi Code, PDF417, Data Matrix (ECC 200 only), QR code, Composite Codes, Aztec|
|Graphics||PPLZ: GRF, Hex and GDI|
|Software-label Editing||BarTender® from Seaguall Scientifi|
|Windows Compatibility||Win CE. NET, Pocket PC, Windows Mobile, Windows XP/Vista/7|
|Software-utility||Printer Utility, Font Utility|
|Driver tools||Argox Seaguall Driver (Windows XP/Vista/Win7/Win8/Win10)
Argox Linux Printer Driver
Argox macOS Printer Driver
Argox RPi Printer Driver
|Media Type||Direct Thermal continuous receipt, Direct Thermal labels, die-cut, black mark, Direct Thermal sticker|
|Media||Recommended Printing Width: Label/Ticket: 3”(78.5mm) (Max. roll capacity(OD): 2.2”(57mm)) Receipt: 1”(25.4mm) ~ 3”(78.5mm) (Max. roll capacity(OD): 2.2”(57mm)) Thickness: Receipt(0.0508~0.1016mm) / Label: Max. 0.15mm|
|Drop Resistance||1.5 m|
|Printer Dimensions||W 106mm x H 70mm x D 153mm|
|Printer Weight||515g (Printer + Battery )|
|Power Source||Rechargeable 7.4V Lithium-ion, 2200mAh
Universal Switching Power supply. AC input voltage: 100~240V, 50~60Hz. DC Output: 9V, 1.56A
|Battery||Rechargeable 7.4V Lithium-ion, 2200mAh, Operating 8 hours, standby 14 hours|
|Operation Environment||Operation Temperature: 14°F~122°F (-10°C~50°C)
Storage Temperature: -4°F~140°F (-20°C~60°C)
|Real Time Clock||N/A|
|Standard Item||Belt clip, Battery, AC adapter, Cleaning tool, A roll of receipt paper, Quick guide, DVD-ROM|
|Optional Items||Shoulder Strap, Environmental case, Lithium-ion Battery, Single Battery Charger, 4 Bay Battery Charg|
|Agency Listing||CE, FCC, RoHS, BSMI|
|Attention||*Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications.|
